Description

Bike Components:

– Frame: 17″ Aluminium
– Forks: SR Suntour XCM with Lock out
– Brakes: F & R Hydraulic Disc
– Gearing: Shimano derailleurs and shifters
– Chainset: Prowheel
– Wheels: Aluminium Rims
– Tyres: Maxxis
– Inner Tubes: Maxxis
– Handlebar: 660mm Aluminium
– Handlebar Stem: Aluminium GTB
– Seat Post: Quick Release Aluminium
– Paint: Matt Paint
– 27.5″ Wheel with Rear Motor

Rear Motor Details:

– 36V350W Rear Motor
– 12G black spokes with double-wall 27.5″ rim
– Max Speed: 25km/h
– Max Torque: 58N.m
– Connector: Julet brand (quick release waterproof connector)

Battery Information:

– 36V Down Tube Battery
– 36V13Ah, High power 18650 cells
– Down tube type, controller inside

Integrated Controller:

– Sine wave controller, JYT brand
– Low voltage protection: 29V
– Rated current: 7A
– Max. current: 15A
– Waterproof connectors: motor, PAS sensor, and 4 in 1 cable

LCD Display:

– 3.5 “LCD screen display with backlight
– Cable: 31.5cm W/O connector
– 5 Assist levels, and 6km/h traction with holding Down Button

PAS Sensor:

– Wuxing Brand, Left installation
– Immediate interruption of the power
– Cable: 30cm W/O connector

Throttle:

– Wuxing Brand, Thumb throttle, 6km/h
– Cable: 30cm W/O connector

Waterproof Connection Cable (4 in 1):

– 4 in 1 waterproof connectors (quick release)
– Cable: 150cm W/O connectors
